Model Number | SXF-1000W-W | SXF-1500W-W | SXF-2000W-W | SXF-3000W-W |
Laser power | 1000W | 1500W | 200W | 3000W |
Dimension | 870x400x705mm | 870x400x705mm | 870x400x705mm | 1125x520x880mm |
Weight | 75kg | 80kh | 85kg | 130kg |
Max. power required | 5kW | 6.5kW | 9kW | 13kW |
Input voltage | 220VAC, 50/60Hz | 220VAC, 50/60Hz | 220VAC, 50/60Hz | 380VAC, 50/60Hz |
Cooling method | Internal water-cooled | Internal water-cooled | Internal water-cooled | Internal water-cooled |
Operation temp. | 0 ~ 45 degree C | 0 ~ 45 degree C | 0 ~ 45 degree C | 0 ~ 45 degree C |
Laser wavelength | 1070nm | 1070nm | 1070nm | 1070nm |
Welding handle length | 10m | 10m | 10m | 10m |
Welding speed | 0-2m/min | 0-2m/min | 0-2m/min | 0-2m/min |
Welding thickness | 0.4-3mm | 0.4-4mm | 0.4-6mm | 0.4-8mm |
Scan width | 0-8mm | 0-8mm | 0-8mm | 0-8mm |
Welding material | Carbon steel, stainless steel, aluminum, galvanized material & other metal materials | |||
Pointing light | Red light | |||
Capable of functionality | Welding, cutting, cleaning | |||
Adapted welding wire dia. | 0.8/1.0/1.2/1.6/2.0mm | |||
Automatic wire feeding | Standard configuration | |||
Welding wire specs. | Solid coiled wire, same as gas-shielded wire | |||
Welding wire material | Same as welded base material | |||
Protective gas | Nitrogen, argon, carbon dioxide | |||
Protective gas flow rate | 10-15 liters per minute | |||
Packing List
1) Laser welding machine, including 10m of welding wire, one unit
2) Wire feeder, including wire feed tube, wire feed wheel accessories, one set
3) Safety goggles, one pair
4) Welding nozzle, five pcs
5) Protective lens, 18*2, five pcs (disposables)
6) Nozzle assembly, including 0.8/1.0/1.2/1.6mm wire nozzle and wire feeder, one set
7) Protective gas connection fittings, one piece
